- Length Over All 47 m. – 154’
- Length Waterline 40,67 m. – 133’
- Beam 9 m.
- Draft 2,47 m.
- Displacement 290 tons (not loaded) - 495 GT
- Type Motor Yacht
- Construction Composite E-Glass/Epoxy/ PVC-Corecell Foam
- Engines 2 X MTU 12V 2000 M72 1450 hp @2250 rpm
- Generators 2 X Kohler 100 kw. 1 X Kohler 50 kw (Harbour Generator)
- Max. Speed 15 Knots
- Cruising Speed 10 Knots
- Range at 10 Knots 3000 Nm. Approx.
- Tank Capacities Fuel 51000 L. Fresh Water 10800 L. Collecting 8000 L.
- Sewage Treatment Hamann Sewage Treatment System
- Vacuum System Evac Vacuum System
- Stabilizer Arcturus Marine Trac 540’ Zero Speed Stabilizer
- Thrusters American Bow Thrusters 20’ Bow-Stern Thrusters
- Accommodation For Guests 10 (1 Owner Cabin & 4 Guest Cabins)
- Accommodation For Crews 9 (1 Captain Cabin & 4 Crew Cabins)
- Classification RINA Charter Class Unrestricted Notation MCA LY2 Code
- Builder & Naval Architect CMB Yachts
- Structural Engineers High Modulus / SP GURIT – England
- System and Electrical Engineers CMB Yachts
- Styling & Design CMB Yachts
- Interior Design Tara Bernerd & Partners - England
