- Length Over All 45,95 m. – 152’
- Length Waterline 40,67 m. – 133’
- Beam 9 m.
- Draft 2,40 m.
- Displacement 270 tons (not loaded) - 455 GT
- Type Motor Yacht
- Construction Composite E-Glass/Epoxy/ PVC-Corecell foam
- Engines 2 x MTU 12V 2000 M72 1450 hp @2250 rpm
- Generators 2 x Northern Lights 105 kw. 1 x Northern Light 55 kw. (Harbour Generator)
- Max. Speed 16 knots
- Cruising Speed 10 knots
- Range at 10 Knots 3000 nm. approx.
- Tank Capacities Fuel 51000 L. Fresh Water 10800 L. Collecting 8000 L.
- Sewage Treatment Hamann Sewage Treatment System
- Vacuum System EVAC Vacuum System
- Stabilizer Arcturus Marine TRAC 540’ Zero Speed Stabilizer
- Thrusters American Bow Thrusters 20’ Bow-Stern Thrusters
- Accommodation For Guests 10 (1 Owner Cabin & 4 Guest Cabins)
- Accommodation For Crews 9 (1 Captain Cabin & 4 Crew Cabins
- Classification RINA Charter Class Unrestricted Notation MCA LY2 Code
- Builder & Naval Architect CMB Yachts
- Structural Engineers High Modulus / SP GURIT – England
- System And Electrical Engineers CMB Yachts
- Styling DIANA Yachts Design - Netherland
- Interior Design Schnaase Interior Design - Germany
